Hitch Weight
575 lb.
7,575 lb.
5,418 lb.
2,157 lb.
Exterior Length
28' 2"
Exterior Height
10' 10"
Exterior Width
Fresh Water
40 gal.
Gray Water
30 gal.
Black Water
30 gal.
Awning Size

Specifications Definitions

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GCWR (Gross Combined Weight Rating) – is the maximum permissible loaded weight of your motor home and any towed trailer or towed vehicle. Actual GCWR of this vehicle may be limited by the sum of the GVWR and the installed hitch receiver maximum capacity rating; see hitch rating label for detail.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.

Note: Specifications are subject to change without notice.

  • Interior Features

    • Mortise and Tenon Shaker Style Cabinets
    • 12-Volt Exhaust Fan and Light
    • Shelving In Overhead Kitchen Cabinets
    • Wood Drawers With Furniture Grade Plywood Sides
    • TV & Cable Prep In Living Room and Bedroom
    • Furnace W/ Digital Thermostat
    • Strut Lifted Storage Under King Bed
    • Increased Foot Space At The Foot of Bed
    • Solid Bedroom Privacy Doors
  • Security & Safety Features

    • LP Leak, Smoke & Carbon Monoxide Detectors
    • Fire Extinguisher
    • Welded Heavy Duty Safety Chains
    • Electric Brakes (All Wheels)
    • GFCI Receptacles
    • ANSI 119.2 Certified
    • Meets All National Highway Administrative Specifications
    • RVIA Approved Product
  • Comfort Package

    • 81" Interior Ceiling Height
    • Solid Privacy Bedroom Door (where applicable)
    • Cable/Satellite Ready
    • USB Charging Stations (Beds, Bunks, & Tables (where applicable))
    • 3-Burner Range & Oven
    • Upgraded Congoleum® Designer Linoleum Flooring
    • Skylight Above Shower/Tub
    • Window Valence Package with Night Shades
    • 2 Zone Sound System With Bluetooth & HDMI Connectivity
    • 48" Dinette (where applicable) With Pullout Storage Drawers Underneath On Roller Guides
    • Porcelain Foot Flush Toilet
    • Backsplash Window In Kitchen
    • Designer Countertops
    • ABS Tub Surround & Cabinet in Bath (where applicable)
    • 35,000 BTU Furnace
    • Extra Large Dinette Picture Windows
    • Marine Grade Woven PVC Flooring in Slide-Outs *No Carpet*
  • Outdoor Enthusiast Package

    • Universal Docking Station
    • Fender Skirt
    • Fully Finished Pass Thru Storage
    • Water Heater Bypass
    • Larger Pass-Thru Storage Door
    • Black Tank Flush
    • Radial Tires
    • Power Awning with LED Lights
    • Enhanced Outside Kitchen Grills (where applicable)
    • Outside Shower with Hot & Cold Water
    • High Definition/Amplified TV Antenna
    • Backup Camera Prep
    • True Solar Prep Roof Mounted MC4 with Pre Wire
    • Exterior LED Lights
    • Detachable Power Cord
    • Power Tongue Jack with LED Light
    • Exterior Oversized Swing Arm Entry Assist Handle
    • Stabilizer Jacks
    • Two Marine Grade Exterior Speakers
    • Tinted Safety Glass Windows
    • Upper Bunk Window
    • R.V.Q. Quick Connect (where applicable)
    • MORryde StepAbove® Triple Entry Solid Step
    • Winegard® Air 360+ HDTV Antenna WiFi Prep 4G LTE Prep
    • Solar Control w/ Mounted 100W Panel
  • Mandatory Options (Standard)

    • Electro-Deposition Coated Frame
    • King Bed - 72” X 80”
    • Enclosed & Heated Underbelly
    • Enclosed Holding Tanks
    • Electric Flush Floor Slide Outs (where applicable)
    • 15,000 BTU Ducted Air Conditioner with Quick Cool
    • Upgraded Interior Design Package
  • Options

    • Goodyear® Tires
    • Goodyear® Spare Tire and Carrier
    • Large 40” LED TV with Bracket
    • Medium 32” LED TV with Bracket
    • 50 Amp Service with 2nd Air Prep
