Hitch Weight
1,655 lb.
13,655 lb.
10,184 lb.
3,471 lb.
Exterior Length
33' 4"
Exterior Height
13' 2"
Exterior Width
Fresh Water
64 gal.
Gray Water
88 gal.
Black Water
44 gal.
Awning Size
10'6" & 14'

Specifications Definitions

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GCWR (Gross Combined Weight Rating) – is the maximum permissible loaded weight of your motor home and any towed trailer or towed vehicle. Actual GCWR of this vehicle may be limited by the sum of the GVWR and the installed hitch receiver maximum capacity rating; see hitch rating label for detail.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.

Note: Specifications are subject to change without notice.


    • Automatic Leveling System
    • Solid Surface Kitchen Countertops
    • Seamless Fiberglass Shower
    • 50" LED Television w/ Swing Arm
    • Furrion™ HDMI/AM/FM Bluetooth Entertainment System w/ Sound Bar Speakers
    • 30" Over-The-Range Residential Microwave
    • Metal Slam Latch Cargo, LP & Outside Kitchen Doors
    • 10 Gallon Water Heater
    • Washer/Dryer Prep
    • <strong>Universal All-In-One Docking Station</strong>
    • Outside Shower w/ Quick Connect Hose and Spray Nozzle
    • Waste Tank Flush
    • PowerFill Fresh Water Tank for Dry Camping
    • Exterior Water Pump Switch
    • Siphon Fill or Sanitize Fresh Water Tank From Vessel Using Water Pump
    • EZ Winterization Valve
    • Battery Kill Switch

    • 15,000 BTU Main A/C
    • Wired & Framed for 2nd A/C
    • Ductless Flooring Throughout Living Area
    • 35,000 BTU High Capacity Furnace
    • 48" Wide 5,100 BTU Electric Fireplace
    • 12v Heat Pads on Holding Tanks
    • Heated, Insulated & Enclosed Underbelly & Dump Valves w/ Circulating Heat
    • Radiant Technology Composites™ Insulation in Roof, Front Cap & Underbelly (Calculated R-38 @ 80° Ambient)
    • Formaldehyde Free Fiberglass Insulation in Roof, Front Cap & Main Floor
    • Laminated Sidewalls, Slide-out End Walls, Slide-out Roofs, Rear Wall and Front Bulkhead Wall w/ Azdel Composite Panels & 1.5 LB Block Foam Insulation
    • Dual Attic Vents

    • Aerodynamic Fiberglass Front Cap
    • Seamless High Visibility LED Front Cap Lights
    • Marine Grade 10" LED Hitch Light
    • LED Marker Lights
    • LED Tail Lights with Back-Up Lights
    • MORryde CRE 3000® Suspension
    • Rear View Camera Prep
    • 6,000 lb. Axles & 16" Nitro Filled E-Range Tires (285, 286, 320, 321)
    • 7,000 lb. Axles & 16" Nitro Filled F-Range Tires (375, 385, 386)
    • Under Carriage Spare Tire & Carrier
    • LionsHead Specialty Tire & Wheel "1 Year No Excuses Guarantee" Program
    • 2" Rear Accessory Hitch
    • Driver's Side Automatic Leveling System Control Box

    • Gel Coated Fiberglass Exterior
    • Deep Tint Safety Glass Windows
    • Residential Wood Framed Roof
    • Factory Installed Roof Ladder
    • 5/8" Tongue & Groove Plywood Floor Decking
    • 2" Thick Double Welded Aluminum Framed Sidewalls, Rear Wall, Front Bulkhead Wall & Slide-Out Rooms
    • 50 AMP Electrical Service
    • Detachable 50 AMP Power Cord
    • 60 AMP Converter w/ Charge Wizard Technology & Lithium or Lead Acid Battery Selector Switch
    • 30" Wide x 78" Tall Entry Door
    • Adjustable Power Awning w/ LED Lights
    • High Capacity Water Pump w/ Interior & Exterior Switch
    • EZ Access Low Point Drain Valves
    • 30 lb. LP Bottles (2)
    • LP Quick Connect
    • Exterior Cable/Satellite Hookup in Pass Thru Storage or Outside Kitchen Compartments
    • LED Motion Sensor Lights in Pass Thru Storage and Outside Kitchen Compartments
    • Safety Light Kit: Entry Steps and Under Bedroom Slide-out
    • Marine Grade LED Light at Sewer Termination
    • Double Welded & Fully Framed Window, Entry Door, Cargo Door and Slide-out Openings
    • 3" x 2" Double Welded Aluminum Floor Joists (16" On Center)

    • 6' 4" Tall Main Slide-out Interior Height
    • 6' 6" Tall Main Bathroom Interior Height
    • Artisan Maple Interior Décor
    • Residential Shaker Style Cabinet Doors w/ Hidden Hinges
    • Solid Core Cabinet Stiles
    • Pre-Drilled & Screwed Cabinetry
    • Ball Bearing Full Extension Drawer Guides
    • Hide-A-Bed Sofa (N/A 375 BH)
    • Wall Hugger Theatre Seats
    • Wall Mounted Free Standing Dinette w/ 4 Chairs
    • Slow Rise™ Roller Shades
    • Matte Black LED Kitchen Pendant Lights (2)
    • LED Motion Sensor Lights in Bathroom Hallway & Bedroom Closets
    • Vinyl Flooring in Living Area, Kitchen, Bathroom & Bedroom (No Carpet)
    • Marine Grade Woven PVC Flooring in Flush Floor Slide-outs
    • Deep Seated Stainless Steel Sink
    • Roll Up Stainless Steel Drying Rack
    • Residential High Rise Faucet w/ Pulldown Sprayer
    • Kitchen 12v MAXXAIR MAXXFAN®
    • Pull Out Trash Can in Kitchen Island
    • 14.7 Cubic Foot Residential Refrigerator w/ 1,000 Watt Inverter
    • 21" Oven & Range w/ Flush Mount Range Cover
    • Porcelain Toilet w/ Foot Flush
    • Skylight Over Shower
    • Bathroom 12v Power Vent Fan
    • Extra Large Seamless Lav Top w/ Undermounted Sink
    • Large Medicine Cabinet w/ Mirror
    • 70" x 80" King Bed w/ Residential Bedspread
    • Oversized Underbed Storage
    • Bedroom Cable/Satellite Hookup

    • 12 Cubic Foot 4 Door Gas/Electric Refrigerator
    • 60" x 80" Queen Bed w/ Residential Bedspread
    • Wall Mounted Booth Dinette w/ 2 Benches
    • 2nd Adjustable Power Awning w/ LED Lights
    • Ducted 2nd A/C
    • Generator Prep
    • Roof Mounted Solar Prep
